3 Core Submersible Flat Cables

1100 V Grade annealed bare electrolytic high conductivity multi stranded copper conductor polyethylene coated, PVC insulated and overall matt finish sheathed flat 3 core waterproof and weatherproof submersible cables as per IS : 694 / 1990. 1100 V Grade annealed bare electrolytic high conductivity multi stranded copper conductor PVC insulated and overall matt finish sheathed flat 3 core submersible cables as per IS:694/1990. Range: 10 sq.mm to 185 sq.mm. These are used to connect submersible pump motor with supply lines. The slot available in the tube well being narrow the shape of the cables has to be suited for such an application.

Features

• Excellent resistance to water, moisture, abrasion, grease and oil
• Longer flex life
• Excellent mechanical & electrical properties

Range: 1.5 sq mm to 120 sq mmApplication

Unique 3 Core Flat Cables are manufactured keeping in mind the severe and difficult conditions in which they are required to perform. The area of installation is physically restrictive, and the environment is every hostile. These are used to connect submersible pump motor with supply lines. The slot available in the tube well being narrow the shape of the cables has to be suited for such an application. Certain striking features of our Flat Submersible Pump cables include excellent resistance to water, moisture, abrasion, grease, oil, long flex life, excellent mechanical & electrical properties
